Service Manual for Crown - Generic Parts Service Crown PTH and PTH50 Service & Maintenance This on-line manual is intended for basic service and maintenance of the Crown pallet jack. The pallet jacks you are servicing are tools that make moving products easier. Operating pallet jacks with rusty, broken or worn parts makes usage and maintenance more difficult. Pallet jack parts are inexpensive and easy to replace. To ensure maximum life from the jack, always replace the parts that are broken or worn.

1. Forklift Reach Truck Training
2. Forklift Reach Truck

Remember that all parts on a pallet jack depend on the adjoining parts to work properly and to perform to their full potential. When used in conjunction with our catalog, this service manual will explain how and when to replace a pallet jack part. Remember, when in doubt. If you have any questions, just call us.

We make it easy! Contents: ©2012 Generic Parts Service, Inc.

All rights reserved. Crown PTH and PTH50 pallet jacks are products of Crown Equipment Corp. Suggested Assemblies to Save Repair Time PTH50. CR 44506-001-D-SUPER Super Ultra-Poly Load Roller Assembly. CR 44495-001 Ultra-Poly Steer Wheel Assembly. CR 44648-SUPER Super Seal Kit.

CR 44521-012 Handle Assembly. CR 44527-A Rod and Chain Assembly. CR 44533-A Chain Assembly. CR RPK50 Roll Pin Kit PTH. CR 82283-1-D-SUPER Super Ultra-Poly Load Roller Assembly. CR 41275-1-D Ultra-Poly Steer Wheel Assembly.

CR 43023-SUPER Super Seal Kit. CR 41293 Handle Assembly.

CR 41295-A Rod and Chain Assembly. CR 79904-A Chain Assembly.

CR RPK Roll Pin Kit. Commonly Used Tools. Hammer. Jack stand. 45° Snap ring pliers (large and small). 13 mm Wrench (for entry rollers).

3 mm Allen wrench. 3/16' Pin punch. 3/8' Pin punch. Crown Bushing extractor (this custom tool is available only through us). Soft hammer (nylon mallet). Anti-seize compound. Lubricant (i.e.

WD40 may be necessary to remove rusted parts) Helpful Reminders. Never hammer directly on an axle; always use a pin punch. Always replace old roll pins. The PTH 50 has blind roll pin holes in the pivot axle and in the shoulder pins.

It is very important to use the correct roll pin in these locations to prevent damage to the mating parts. Replace accessible bushings whenever the jack is disassembled. Our custom designed bushing extractor makes it quick and easy to remove all bushings on the Crown jack. Serial numbers can be found on the A-Frame.

Crown PTH Serial numbers are 3-118400 to 3-999999. Crown PTH50 Serial numbers are 7-000000 and higher. Axles Inspection If the axle is bent, out-of-round, or shows signs of wear, replace it. Check for worn roll pin holes. If these are damaged or worn, replace the axle. Bushings Bushings are designed to wear out sooner than the mating parts.

They are made of softer material and are expendable. It is recommended that anytime the jack is torn down to a point where the bushings are accessible, they be replaced. This will ensure longer life of the jack and will reduce the amount of downtime. Bushings are very inexpensive and it is cost effective to change them regularly. Inspection If bushings are cracked, broken, egg shaped or worn more than 1/16' from the original size replace them.

Remember: If the jack is already disassembled, replace all accessible bushings. Tip: Coating axles and bushings with anti-seize compound before installation makes maintenance easier. Load Rollers and Load Roller Brackets Inspection Load rollers - Load rollers should have neither flat spots nor large pieces of metal imbedded in them (i.e. Tacks, nails or metal shavings). Any chips in the wheel that keep it from rolling smoothly indicate the need for replacement. If the wheel has cracks, loose tread, or does not turn freely, replace both wheels. Always change the wheels in pairs to reduce uneven wear.

New load rollers have an outside diameter of 3' (PTH50) or 3 1/4' (PTH). If the diameter is is worn more than 1/4' from normal size, replacement is necessary. Load roller brackets - Inspect the brackets for cracks or wear from prolonged rubbing on the floor. Check for out-of-round axle holes and inspect the bushings closely (see Bushing Inspection). If any of the above conditions exist, replace the brackets. Removal Tip: We recommend servicing one load roller assembly at a time, while using the other assembly as reference.

PTH Load roller - Pump the jack to expose the load roller brackets and then turn the jack on its side. Use a hammer and pin punch to remove both of the roll pins in the load roller brackets that secure the load roller axle in place.

Drive the axle out with the punch and remove the load roller. (10 minutes) Load roller brackets - Remove the load roller. Drive the roll pins out of the pivot axle that hold the exit roller in place, as well as the roll pin that fastens the pivot axle to the frame. Drive the pivot axle out, pull the push rod away from the frame, and pull the brackets off of the push rod.

(15 minutes) Installation PTH Load roller brackets - Slide the brackets on to the push rod. Insert the pivot axle through the frame, brackets and the exit roller. Secure the pivot axle to the frame with the roll pin. Position the exit roller between the two roll pin holes, then hammer the two roll pins in to keep the exit roller in place. (15 minutes) Load rollers - Insert the load roller axle through the brackets and load roller, then secure the axle to the brackets with the two roll pins. (10 minutes) Removal PTH50 Load roller - Pump the jack to expose the load roller brackets and then turn the jack on its side. Use a hammer and pin punch to remove both of the roll pins in the load roller brackets that secure the load roller axle in place.

Drive the axle out with the punch and remove the load roller. (10 minutes) Load roller brackets - Remove the load roller. Drive the roll pin that fastens the pivot axle to the frame into the axle (this is a blind roll pin hole). Remove the pivot axle just enough to be able to drive the roll pin out of the axle, then drive the pivot axle completely out. Pull the push rod away from the frame and pull the brackets off of the push rod. (15 minutes) Installation PTH50 Load roller brackets - Slide the brackets on to the push rod.

Insert the pivot axle through the frame, exit roller and brackets. Line up the roll pin hole and secure the pivot axle to the frame with the roll pin. (15 minutes) Load rollers - Insert the load roller axle through the brackets and load roller, then secure the axle to the brackets with the two roll pins. (10 minutes) Steer Wheels and Axle Inspection Steer wheels should have neither flat spots nor large pieces of metal imbedded in them (i.e. Tacks, nails, or metal shavings). Chips in the wheel which keep it from rolling smoothly indicate replacement. Steer wheels should turn freely.

They should not rub the bottom of the traverse. If they do, check for the correct installation of the snap ring under the traverse. The PTH50 uses 7' wheels, and the PTH uses 8' wheels. If the diameter is worn more than 1/4' from the normal size, replacement is necessary. Removal PTH Steer wheels - Turn the jack onto its side, remove the snap ring attaching the wheel to the axle, and the wheel may be removed. (10 minutes) Steer wheel axle - Turn the jack onto its side.

Remove the steer wheels, the roll pins and fastening pin connecting the steer wheel axle to the bottom of the hydraulic unit. The axle will slide out.

(15 minutes) Steer wheels - Remove the hubcap and then the snap ring. The wheel is now free and may be removed. (10 minutes) Steer wheel axle - Turn the jack onto its side. Remove the hub cap and the snap ring, and slide the steer wheel off of the axle.

Remove the roll pin holding the axle to the hydraulic unit stem and drive the axle out with a soft hammer. (15 minutes) Installation PTH Steer wheels - Slide the wheel onto the axle and attach the snap ring. (10 minutes) Steer wheel axle - Slide the axle into the bottom of the hydraulic unit and secure with the fastening pin and its roll pins. Then slide the steer wheels on to the axle and attach snap rings.

(15 minutes) PTH50 Steer wheels - Slide the wheel onto the axle and attach the snap ring. (10 Minutes) Steer wheel axle - Slide the axle into the bottom of the hydraulic unit and fasten with the roll pin. Then secure the steer wheels.

(15 Minutes) Traverse Inspection There are few things that can be wrong with the traverse. Wear can occur on the bearing shoulder or where the shoulder bolts attach to the lifting link. If these areas are egg-shaped or out of round, replace the traverse. Removal Pump the jack to maximum height and turn the jack onto its side. Remove the steer wheels and axle (see Steer Wheels and Axle Removal) and the snap ring under the traverse on the stem of the hydraulic unit. Turn the jack upright; be careful no to damage the stem of the hydraulic unit while lowering. Remove the roll pin that fastens the top of the ram to the frame.

Lift the frame off of the ram, tip the handle and hydraulic unit away from the frame, and rest both pieces on the ground. Remove the ball on top of the ram (PTH50 only) and pull the hydraulic unit out of the traverse. On the PTH, remove the roll pins holding the shoulder pins in the traverse.

Remove the shoulder pins and the traverse. On the PTH50, use a pin punch and hammer to drive the shoulder pins roll pins into the shoulder pins until they are flush. Remove the shoulder pins and the traverse. (20 minutes) Installation Attach the traverse to the lifting link with the shoulder pins and secure the shoulder pins with the roll pins. Slide the stem of the hydraulic unit into the traverse with the traverse bearing already in place on the stem. Insert the ram into the A-Frame with the ball positioned on the top of the ram and secure the ram to the A-Frame with the screw.

Carefully turn the jack onto its side, keeping the hydraulic unit in the traverse and frame. Attach the snap ring to the stem of the hydraulic unit under the traverse.

Install the steer wheel assembly (see Steer Wheels and Axle Installation) and the handle, if necessary (see Handle Installation). Bleed the hydraulic unit (see Air Lock and Pump). (20 minutes) Push Rods Inspection When inspecting the push rods, look for broken or cracked welds, bends, and out-of-round holes. If any of the above conditions exist, replace the push rod. We suggest that you work on one side of the jack at one time, so you can use the other side as a reference. Removal Turn the jack over so the undercarriage is facing up.

Remove the load roller brackets (see Load Roller Brackets). On the PTH, remove the roll pin and pin that fastens the push rod to the lifting link.

On the PTH50, remove the roll pin that fastens the push rod to the lifting link. (20 minutes) Installation Turn the jack over so the undercarriage is facing up. Set the push rods in the frame. The end of the push rod connecting to the load roller brackets is angled. The push rod should be positioned such that the angled side faces the ground when the jack is turned upright. Slide the push rod onto the lifting link and fasten by inserting the roll pin. On the PTH, install the pin that connects the push rod to the lifting link and insert the roll pin.

Install the load roller brackets (see Load Roller Brackets Installation). (20 minutes) Lifting Link Inspection Check the lifting link for out of round holes, cracks in welds, or bent ears.

If any of these conditions exist, replace the lifting link. Also check the integrity of the bushings, shoulder pins, lifting link pins or the roll pins that fasten these parts to their mating parts. Removal First, remove the hydraulic unit (see Hydraulic Unit). Remove the traverse (see Traverse). Remove load roller brackets (see Load Roller Brackets) and both of the push rods (see Push Rods). Remove the roll pins that fasten the lifting link pins to the frame. Extract the lifting link pins from the frame and then the lifting link.

(35 minutes) Installation Place the lifting link in position and insert the lifting link pins. Insert the roll pins that fasten the lifting link pins to the frame. Install the push rods (see Push Rods).
